DURASILE AF-HT-WR Non Asbestos Gasket Sheets -Metallic
550 INR/Kilograms
Product Details:
- Hardness Yes
- Usage Sealing Industry, Fluid Industry, Oil & Gas Industry, Power Plants, Gasket Industry.
- Size 1500mm X 1500mm, 1500mm X 2000mm, 1500mm X 2250mm, 1500mm X 3000mm, 1500mm X 4500mm, 2000mm X 3000mm
- Pressure Resistance 150 bar
- Length 4500 Millimeter (mm)
- Color Grey/Graphite
- Temperature Resistance 400 C
- Click to View more
X
DURASILE AF-HT-WR Non Asbestos Gasket Sheets -Metallic Price And Quantity
- 3000 Kilograms
- 550 INR/Kilograms
- 550.00 - 2500.00 INR/Kilograms
DURASILE AF-HT-WR Non Asbestos Gasket Sheets -Metallic Product Specifications
- 1500mm X 1500mm, 1500mm X 2000mm, 1500mm X 2250mm, 1500mm X 3000mm, 1500mm X 4500mm, 2000mm X 3000mm
- Other
- 150 bar
- Sealing Industry, Fluid Industry, Oil & Gas Industry, Power Plants, Gasket Industry.
- 4500 Millimeter (mm)
- Other
- Yes
- Sealing Industry, Fluid Industry, Oil & Gas Industry, Power Plants, Gasket Industry.
- Non Asbestos Gasket Sheets
- 400 C
- 1500 Millimeter (mm)
- BS 7531 Grade X
- Grey/Graphite
- 400 C
- 0.80mm to 6.00mm Millimeter (mm)
DURASILE AF-HT-WR Non Asbestos Gasket Sheets -Metallic Trade Information
- ICD TKD
- 300000 Kilograms Per Month
- 7 Days
- Yes
- Free samples are available
- Export Friendly Strong Wooden Pallets
- Asia Australia Central America North America South America Eastern Europe Western Europe Middle East Africa
- All India
- ISO 9001:2015
Product Description
DURASILE AF-HT (Non-Metallic) ï High-Temperature Non-Asbestos Gasket Sheet
Compressed Non-Asbestos Fibre (CNAF) Gasket Material for High-Performance Industrial Sealing Applications
Product Overview:
DURASILE AF-HT is a premium-grade high-temperature compressed non-asbestos (CNAF) gasket material engineered for demanding industrial applications. Designed to deliver exceptional thermal and chemical resistance, it is ideal for sealing in power plants, oil & gas industries, sugar mills, and chemical processing units. This high-strength material provides reliable sealing under elevated temperatures and pressures in compressors, pumps, transmission systems, gas meters, internal combustion engines, and pipeline assemblies.
Key Features & Applications:
- High-performance non-asbestos gasket sheet for thermal insulation and sealing
- Excellent resistance to high temperatures, steam, oil, fuels, and gases
- Suitable for use in compressors, apparatus housings, boilers, and pipeline joints
- Commonly used in chemical processing, power generation, and general industrial maintenance
- Reliable sealing under high temperature and medium pressure conditions
Material Composition:
DURASILE AF-HT is manufactured using a reinforced blend of aramid fibres and mineral fibres, bonded with durable nitrile rubber (NBR). The material is produced through a hot calendaring process, ensuring dimensional stability, mechanical strength, and uniform performance across all sheets. The production process complies with stringent ISO 9001 quality standards, offering consistent, reliable performance in critical industrial sealing environments.
Standards & Compliance:
- Complies with BS 7531 Grade X
- ASTM F104 Specification: F719911A9B3E19M6
- Manufactured under a certified ISO 9001 quality management system
Advantages:
- High temperature resistance ï ideal for steam and engine applications
- Excellent sealing performance under dynamic mechanical and thermal stress
- Non-asbestos composition ï safer, modern alternative to traditional gasket materials
- Durable and oil-resistant ï compatible with a wide range of industrial fluids Ideal for medium-to-high temperature sealing applications across various industries
Technical Details
| Parameter | Specification |
|---|---|
| Maximum Peak Temperature (C) | 400 C |
| Maximum Operating Temperature (C) | 270 C |
| Maximum Peak Pressure (bar) | 150 bar |
| Available Thickness (in mm) | 0.80 to 5.00 (other thickness available on request) |
| Available Colors | Grey/Graphite |
| Available Sheet Sizes (in mm) | 1500 X 1500, 1500 X 2000, 1500 X 2250, 1500 X 3000, 1500 X 4500, 2000 X 3000 |
